The Factory Method pattern is, in my opinion, the most beautiful and elegant pattern in the Gang of Four book. Its short definition has helped the industry confuse it with the much simpler Factory pattern. I think we have largely lost the real pattern to that naming collision. Member managers and email services, Windows Forms and user controls, and cars and engines give us three ways to see its structure.

The definition is beautifully compact once you know the pattern. When I was teaching it, I had some fun with how little help that compact wording gives someone hearing it for the first time. It can sound written to impress the people who already know the answer. I would rather stop and answer four plain questions: Which interface? Which object? Whose subclasses? An instance of what? Then the elegance becomes useful.

What the creation method belongs to

The definition says to provide an interface for creating an object and let subclasses decide which class to instantiate. Here, interface describes the way a class offers that creation operation. The pattern does not require a language interface type.

What object is being created? A dependency of the class that defines the method. Imagine a Car that needs an Engine. The Car base class offers a method to make an engine. Subclasses of Car can override that method to choose a different engine.

I make that method protected and virtual: descendants need to override the choice, while callers have no reason to select an engine by invoking the hook themselves. A base class can supply a default engine or leave the method abstract.

Now there are two families in view:

  1. The consumers: Car and its descendants.
  2. The dependencies: Engine and its descendants.

The two hierarchies are the telltale sign of Factory Method. The creation hook belongs to the consumer hierarchy, where a descendant overrides it. The hook returns the dependency hierarchy’s base type, even though the override may construct a particular descendant. The families do not need matching numbers of descendants. A separate Factory also returns a product through its base type, but it does not have this consumer hierarchy with an overridable creation hook.

A member manager and its email service

A MemberManagerBase uses an EmailServiceBase during its DoSomeWork sequence. If the manager constructs the email service directly, descendants cannot vary that choice. Extracting a protected creation hook, MakeEmailService, gives them that choice. Its return type is EmailServiceBase. The production MemberManager overrides the hook to create the real EmailService.

The inherited workflow uses the email service through its base type. A property can initialize it when first needed and then reuse that instance. The timing of construction is a detail of this example; the pattern is the override that chooses which member of the email-service family the manager receives.

An EmailServiceStub and a test manager that overrides the same hook can demonstrate the variation. The workflow still runs, but the stub reports that no emails were sent. If the test is meant to exercise behavior in MemberManager, the test subclass should descend from MemberManager and change only the creation hook. This changes the dependency without replacing the manager behavior under test. Such a check demonstrates the workflow with substituted email behavior; it does not verify real email delivery.

A form and its user control

In a Windows Forms application, FormBase has a MakeUserControl hook that returns UserControlBase. The base form can supply the base control itself; FormChildOne and FormChildTwo override the hook to supply their own descendant controls. One child control displays a check box, and the other a combo box. Each form displays the control chosen by its override.

A control’s Windows Forms Parent property identifies its containing control. That containment relationship is separate from the two inheritance hierarchies: the forms are one family, and the user controls are the other. The base form can use the result as UserControlBase in every case.

A shorter way to see the hook

Cars and engines give us a smaller example with both families defined inline. This runnable teaching implementation writes messages to show which engine starts:

public abstract class Engine
{
    public abstract void Start();
}

public sealed class StandardEngine : Engine
{
    public override void Start()
    {
        Console.WriteLine("Standard engine started");
    }
}

public sealed class V12Engine : Engine
{
    public override void Start()
    {
        Console.WriteLine("V12 engine started");
    }
}

public abstract class Car
{
    public void Drive()
    {
        Engine engine = MakeEngine();
        engine.Start();
    }

    protected virtual Engine MakeEngine()
    {
        return new StandardEngine();
    }
}

public sealed class SportsCar : Car
{
    protected override Engine MakeEngine()
    {
        return new V12Engine();
    }
}

Both families are used through their base types. A caller can hold a SportsCar as a Car and invoke Drive without depending on the car’s concrete class. Inside Drive, the variable is declared Engine engine, even when MakeEngine creates a V12Engine. The inherited operation calls the public Engine contract without knowing which engine descendant it received. The subclass knows what it constructs; the code using the returned engine does not. These are intentional uses of polymorphism, and neither requires a separate language interface type.

A consuming operation can receive the car through that base contract:

public static class CarConsumer
{
    public static void Drive(Car car)
    {
        car.Drive();
    }
}

When supplied with a SportsCar, this operation prints V12 engine started. It calls only Car.Drive; the inherited workflow obtains its engine through the overridable hook.

The hook can have a default implementation, as in the car and Windows Forms examples, or be abstract when every subclass must make the choice, as in the member manager example.

A car may also need tires, seats, and lights. Each dependency whose construction a subclass must control can have its own Make hook. The two families remain the clue: the family containing the hooks and the family whose objects those hooks create.

The word Make is my naming convention for this hook. I use CreateInstance for the separate Factory pattern. The prefix is a small signal in code where these similar names otherwise cause confusion.

How this differs from a Factory

A Factory is a separate construction class. It can inspect business input and return a concrete descendant through a base type. It does not have to participate in an inheritance hierarchy of consumers.

Factory Method puts the construction operation on a consumer’s base class and lets that consumer’s subclasses override it. The subclasses decide how to create a dependency used by the inherited behavior. A method that merely creates an object is not enough to establish this pattern; the override relationship matters.

“Program to an interface, not an implementation” is a rule about the call site. The variable’s base type gives the caller the base class’s public contract, while the actual object may be any compatible descendant. A language interface type is one way to express such a contract, but it is not required here.

A later design preference

Factory Method uses inheritance to vary construction. In new designs, my preference is for protocols and composition when a dependency must vary. A class can receive a dependency or a focused factory, or a context can own the choice. I avoid inheritance for extension in new designs, so I would rarely choose Factory Method there.

I still want the pattern understood and named correctly. The two families and the overridable creation hook explain what it does. Whether I would use inheritance for that variation in a new system is a separate decision.
