An order must be recorded atomically. The database must supply catalog prices and reject a conflicting reference. Fulfillment must receive the required message through the broker. A test needs to exercise those responsibilities in the infrastructure that performs them.
About the examples: Meridian Ordering is a private training reference project. The inline listings illustrate the techniques; the full C# and Python repositories are not currently public.
Meridian runs its order scenarios against real SQL Server and a real broker. Its ordinary CI configuration uses RabbitMQ. Its teaching email integration captures requests; a stable real provider can support the separate delivery arrangement.
The purpose is confidence to go to production. First establish the business requirements, acceptance criteria, functional requirements, and non-functional requirements and verify that scenarios and expectations correctly cover them. Real infrastructure then participates in executing and observing those outcomes.
Identify what must participate in this order
For an accepted order, arrange:
- SQL Server with the actual schema and procedures. The operation checks database facts and records order, lines, and initial action state.
- The seeded catalog. Arrange reads expected names and prices; production reads catalog facts at placement time.
- A provisioned fulfillment destination. Production publishes through its configured adapter.
- An isolated subscriber opened before Act. The test receives its own copy and correlates the message with this order.
- The facade’s email capture. The gateway constructs its request and the test observes it at the handler.
The tables and procedures define constraints and the placement transaction. Using them exercises their effects alongside the production data manager. Returning an arranged order from a substitute could not establish that the transaction committed all required rows or enforced the reference constraint.
Start infrastructure, then provision the application
The Docker Compose configuration starts SQL Server and RabbitMQ for the ordinary local setup. An optional profile starts the Service Bus emulator and its supporting database.
The local setup sequence is:
docker compose up -d
dotnet run --project setup/MeridianOrdering.Setup
dotnet run --project setup/MeridianOrdering.Setup -- run-testsRun from the Meridian repository with its documented SDK and test configuration. Docker starts engines; setup provisions schema, seed data, and broker topology. A running SQL process without the required tables is not a ready order store. A reachable broker without the destination is not a ready messaging arrangement.
These commands belong to the original solution. The accompanying listings are reference material and do not constitute an independently runnable project.
Give each run its own database
The setup runner creates a generated database, hydrates it, passes its connection string to dotnet test, and drops it in finally. Here are selected statements from the runner:
/// Arrange: generate and hydrate the database owned by this run.
var databaseName = $"MeridianOrdering_Test_{Convert.ToHexString(RandomNumberGenerator.GetBytes(6))}";
string disposableConnectionString = CreateAndHydrateDatabase(configuredConnectionString, databaseName, cancellationToken);/// Arrange: point the test process at the newly created database.
dotnetTestStartInfo.Environment[OrderStoreConnectionStringVariable] = disposableConnectionString;These statements come from different points in the method. The runner retains the server and authentication details but replaces the database name. It validates names against its generated pattern before creation or deletion. Cleanup ownership begins after successful creation; hydration failure also attempts owned cleanup.
Cancellation stops the test process before its database is removed. If execution and cleanup both fail, the original exception retains the cleanup failure in its data. Leftover state needs diagnosable cleanup failures.
A fresh database and random record identities address different isolation scopes. The database separates runs sharing a server. Owned identities separate scenarios within that database and make targeted teardown explicit.
Isolate broker observations too
If four developers consume one queue, one consumer can remove another test’s message. Random references identify messages but cannot recover those already consumed elsewhere.
Meridian’s RabbitMQ subscriber creates a private exclusive queue and binds it to the fulfillment exchange. Each test gets a separate copy of publications routed there. The subscriber shows declaration and binding. Its queue can receive other orders too, so the test helper filters by this run’s order reference.
The Service Bus path leases a pre-provisioned subscription from a pool and returns it on disposal. Test assemblies declare disjoint slices of names. Arrangement drains leftovers from the leased subscription before Act. The broker helpers show both paths and bounded lease waiting.
A process-local lease pool cannot coordinate unrelated developers using the same subscriptions. Across machines or independent CI jobs, use disjoint names, separate environments, or an explicit coordination mechanism. Understand the scope of the local ownership mechanism before sharing its infrastructure.
The scenario owns its subscriber with await using:
/// Arrange: open the observation before the order publishes.
await using var subscriberFulfillmentNotifications =
await BrokerSubscriptions.SubscribeToFulfillmentNotificationsForTestAsync();Subscribe first, invoke the order, then gather. Opening after publication could miss the effect being verified.
Give observations defined windows
Meridian allows up to ten seconds to receive the required message. A successful receive returns when the message arrives. It then listens for an additional correlated message during a one-second quiet window:
/// Assert: observe the required message and any extra notification.
var actualFulfillmentNotificationPayload = await BrokerSubscriptions.ReceiveMessageForOrderAsync(
subscriberFulfillmentNotifications, orderPlacementRequest.OrderReference);
var actualExtraFulfillmentNotificationPayload = await BrokerSubscriptions.TryReceiveMessageForOrderAsync(
subscriberFulfillmentNotifications, orderPlacementRequest.OrderReference);The quiet-window assertion establishes that no additional correlated message was observed in that interval. Crash recovery or later replay has separate scenarios. The observation cannot establish absence for all future time.
Use the same discipline for a real inbox: bounded waiting, this run’s identity, and content comparisons after receipt. Provider acceptance and inbox arrival are different observations with different timing.
Verify rollback after the real transaction starts
Meridian’s rollback scenario uses a private hydrated database with an OrderLine insertion trigger that waits ten seconds. The SQL command timeout is two seconds. The actual procedure starts its transaction and reaches the insertion before timeout interrupts it.
The class owns this database:
/// Arrange: create a private database with delayed OrderLine insertion.
private readonly DisposableOrderStore _disposableOrderStoreWithArrangedLineDelay =
DataManagerForTest.CreateDisposableOrderStore(
DataManagerForTest.CreateDisposableDatabaseName(),
arrangedFault: DisposableOrderStoreFault.OrderLineInsertTimeout);Here is the complete rollback scenario, with phase comments marked for reading:
/// Arrange, Act, Assert: exercise a real timeout and verify complete rollback.
public async Task PlaceOrder_WhenOrderLineInsertExceedsCommandTimeout_ThenSqlClientReportsTimeoutAndTheEntireDatabaseOperationRollsBack()
{
/// Arrange - a real schema in a private database, with a valid customer and product.
// Its AFTER INSERT trigger waits ten seconds during OrderLine insertion.
int expectedSqlClientTimeoutErrorNumber = -2;
Type expectedExceptionType = typeof(OrderStoreUnavailableException);
List<string> expectedSqlTimeoutMessagePhrases = ["Execution Timeout Expired"];
var disposableOrderStore = _disposableOrderStoreWithArrangedLineDelay;
var timeoutConnectionStringBuilder = new SqlConnectionStringBuilder(disposableOrderStore.ConnectionString)
{
CommandTimeout = 2,
};
var customerRecord = DataGenerators.CreateCustomerRecord(
customerId: _expectedOrderPlacementIdentifiers.CustomerId,
customerStatus: DataGenerators.ActiveCustomerStatus);
DataManagerForTest.InsertCustomer(customerRecord, disposableOrderStore.ConnectionString);
var catalogProduct = DataManagerForTest.GetRandomCatalogProducts(
productCount: 1,
connectionString: disposableOrderStore.ConnectionString)[0];
// Line items are Set even at quantity 1: the product must come from the private
// disposable store the facade is pointed at, not from the shared store the
// builder's default reads.
var orderPlacementRequest = RequestBuilders.OrderPlacementRequestBuilder
.Set(request => request.OrderReference, _expectedOrderPlacementIdentifiers.OrderReference)
.Set(request => request.CustomerId, customerRecord.CustomerId)
.Set(request => request.OrderPlacementLineItems, [new OrderPlacementLineItem(sku: catalogProduct.Sku, quantity: 1)])
.Build();
var (domainFacadeInstance, testMediatorEmailService, _) = DomainFacadeFactory.CreateDomainFacade(
overrideByEnvironmentVariableName: new Dictionary<string, string>
{
[DataManagerForTest.OrderStoreConnectionStringVariable] = timeoutConnectionStringBuilder.ConnectionString,
});
await using var domainFacade = domainFacadeInstance;
await using var subscriberFulfillmentNotifications =
await BrokerSubscriptions.SubscribeToFulfillmentNotificationsForTestAsync();
var expectedOrderPlacementRecordCounts = new OrderPlacementRecordCounts(
CustomerCount: 1, OrderCount: 0, OrderLineCount: 0, OrderMessagingStateCount: 0);
/// Act - SqlClient's command timeout cancels execution while the trigger waits.
// The data manager's existing SQL-error translation remains under test.
Exception? actualException = await Record.ExceptionAsync(
async () => await domainFacade.PlaceOrderAsync(orderPlacementRequest));
/// Assert - the data manager preserved the SQL client's timeout as the cause.
AsserterSqlClientException.AssertExceptionWasATimeoutException(
actualException: actualException,
expectedExceptionType: expectedExceptionType,
expectedErrorNumber: expectedSqlClientTimeoutErrorNumber,
expectedMessagePhrases: expectedSqlTimeoutMessagePhrases);
/// Assert - the arranged customer remains, but every record created inside the
// PlaceOrder transaction is absent. No side effect was attempted afterward.
var actualOrderPlacementRecordCounts = DataManagerForTest.GetOrderPlacementRecordCounts(
customerId: customerRecord.CustomerId,
orderReference: orderPlacementRequest.OrderReference,
connectionString: disposableOrderStore.ConnectionString);
Assert.Equal(expectedOrderPlacementRecordCounts, actualOrderPlacementRecordCounts);
var actualUnexpectedFulfillmentNotificationPayload = await BrokerSubscriptions.TryReceiveMessageForOrderAsync(
subscriberFulfillmentNotifications, orderPlacementRequest.OrderReference);
AsserterMessageBroker.AssertNoMessageArrived(
actualUnexpectedFulfillmentNotificationPayload,
orderPlacementRequest.OrderReference,
RollbackRule);
AsserterConfirmationEmail.AssertNoEmailSent(testMediatorEmailService.CapturedEmailRequests, RollbackRule);
}The containing class includes database creation and teardown. The database helper includes trigger installation, hydration, name validation, and record-count queries.
The scenario checks the translated timeout and preserved SQL cause, the remaining customer, zero matching orders, lines, and messaging-state records, broker absence, and no captured email. Its expected counts are a structured record compared with fresh reads against the private database.
This verifies rollback after work has begun. Throwing before the first write would exercise a different condition. The private database keeps the deliberate delay away from other scenarios.
Select downstream services the tests can rely on
Real downstream services are appropriate when availability and contract stability are dependable enough for testing. Trusted here means predictable operation and change, including advance notice when contracts will change.
A stable payment sandbox or email integration can be suitable. A dependency that regularly disappears or changes without notice can fail the suite for reasons outside the feature being changed. This is a practical environment constraint; it does not change the purpose of functional acceptance testing at the boundary.
Arrange credentials, owned data, controlled recipients or destinations, capacity, and bounded observation. Account for billable operations and effects that cannot simply be undone. Email can capture the intended recipient and redirect to a controlled inbox. Payment testing can use the provider’s approved test environment and operations. Integration-specific details belong with that implementation.
A selected transport seam can arrange failures on demand while retaining production response handling. The Test Mediator article explains its evidence and what needs a separate real-service observation.
Use real infrastructure at the final CI gate
The checked-in workflow starts the Compose services, waits for healthy infrastructure, builds and checks formatting, provisions the application, then runs tests through the disposable database runner. It configures MERIDIAN_MESSAGE_BROKER_TYPE as RabbitMq. This snapshot demonstrates SQL Server and RabbitMQ in CI. Cloud Service Bus and real-provider email delivery are separate environment choices.
A team can use a local broker for development and its deployed broker in CI by configuration, with appropriate topology and isolation. The final gate should exercise the real infrastructure required for release, subject to the same downstream stability constraints. Record which provider and environment each execution receipt used.
The recorded local verification ran the selected Place Order scenarios and both composer suites against SQL Server and RabbitMQ: 77 passed, with no failures or skips. Assertion-report verification passed all 18 cases. These are local execution receipts; they do not claim a CI or cloud-provider execution for these examples.
Correct arrangements, real infrastructure, and deep assertions work together. The required suite must cover the established scenarios and expectations. That is the release evidence the team maintains as the system changes.
